ADuM6132
Data Sheet
Parameter
Symbol
Min
Typ
Max
Unit
Test Conditions/Comments
Part-to-Part Matching 1
60
ns
C L = 200 pF
Output Rise Time (10% to 90%)
Output Fall Time (10% to 90%)
t R
t F
15
15
ns
ns
C L = 200 pF
C L = 200 pF
1
2
3
4
See the Terminology section.
I DDA is supplied by the output of the integrated isolated dc-to-dc power supply. I DDB is supplied by an external power connection to the V DDB pin. See Figure 16.
Duration less than 1 second. Average output current must conform to the limit shown in the Absolute Maximum Ratings section.
Undervoltage lockout (UVLO) holds the outputs in a low state if the corresponding input or output power supply is below the referenced threshold. Hysteresis is built
into the detection threshold to prevent oscillations and noise sensitivity.
PACKAGE CHARACTERISTICS
Table 2.
Parameter
Symbol
Min
Typ
Max
Unit
Test Conditions/Comments
Resistance (Input Side to High-Side Output) 1
Capacitance (Input Side to High-Side Output) 1
Input Capacitance
R I-O
C I-O
C I
10 12
2.0
4.0
?
pF
pF
Junction-to-Ambient Thermal Resistance
θ JA
45
°C/W
4-layer PCB
1
The device is considered a two-terminal device: Pin 1 through Pin 8 are shorted together, and Pin 9 through Pin 16 are shorted together.
REGULATORY INFORMATION
Table 3.
UL
Recognized under UL 1577
component recognition program 1
Single protection,
3750 V rms isolation voltage
File E214100
CSA
Approved under CSA Component Acceptance
Notice #5A
Basic insulation per CSA 60950-1-03 and IEC 60950-1,
400 V rms (566 V peak) maximum working voltage
Reinforced insulation per CSA 60950-1-03 and
IEC 60950-1, 250 V rms (354 V peak) maximum
working voltage
File 205078
VDE (Pending)
Certified according to DIN V VDE V 0884-10
(VDE V 0884-10):2006-12 2
Reinforced insulation, 560 V peak
File 2471900-4880-0001
1
2
In accordance with UL 1577, each ADuM6132 is proof-tested by applying an insulation test voltage ≥ 4500 V rms for 1 second (current leakage detection limit = 10 μA).
In accordance with DIN V VDE V 0884-10, each ADuM6132 is proof-tested by applying an insulation test voltage ≥ 1050 V peak for 1 second (partial discharge detection
limit = 5 pC). The asterisk (*) marking branded on the component designates DIN V VDE V 0884-10 approval.
INSULATION AND SAFETY-RELATED SPECIFICATIONS
Table 4.
Parameter
Rated Dielectric Insulation Voltage
Minimum External Air Gap (Clearance)
Minimum External Tracking (Creepage)
Minimum Internal Gap (Internal Clearance)
Tracking Resistance (Comparative Tracking Index)
Isolation Group
Symbol
L(I01)
L(I02)
CTI
Value
3750
>8.0
>8.0
0.017 min
>175
IIIa
Unit
V rms
mm
mm
mm
V
Test Conditions/Comments
1 minute duration
Measured from input terminals to output
terminals, shortest distance through air
Measured from input terminals to output
terminals, shortest distance path along body
Insulation distance through insulation
DIN IEC 112/VDE 0303 Part 1
Material Group (DIN VDE 0110, 1/89, Table 1)
Rev. B | Page 4 of 16
